Overall Dimensions (L x W x H): 40”x26”x39” (1016x660x990 mm)
Folded Dimensions (L x W x H): 27”x17”x30” (685x432x762 mm)
Seat Height (from ground): 20” (508mm)
Armrest Height (from seat): 9” (230mm)
Backrest Height (from seat): 18” - 24” (458mm - 610mm)
Max Loading Weight: 350 lbs (159 kg)
Net Weight without Battery: 60 lbs (27.2 kg)
Net Weight with Battery: 67 lbs (30.4 kg)
Battery: 24V 12AH or 24V 20AH lithium-ion
Battery Charge: AC 100-240V, 50Hz,1.5-5A
Battery Charge Time: 6 to 8 hours
Range with 12AH Battery: Up to 13 mile (20km)
Range with 20AH Battery: Up to 19 mile (30km)
Airline and Cruise Approval*: Only with 24V 12AH battery
Max Speed: 4 mph (6 km/h)
Motor: 2 * 250W or 2 * 300W
Controller: 24V 50A
Climbing Angle Max Degrees: 6°
Max Safe Slope: 9°
Static Stability: 9°
Brake: Intelligent electromagnetic break
Turning Radius: ≤ 47” (1200 mm)
Reversing Width: ≤ 49” (1250 mm)
Front Wheel Diameter: 8” (200 mm)
Rear Wheel Diameter: 12” (305mm)
Seating Area Width: 19” (470 mm)
Cushion Size (width x depth): 17.8” (452 mm) x 18” (457 mm)
Controller Type: Detachable All-Direction Joystick
Tire pressure (for pneumatic tire): 30 psi (2 kgf/cm2)
