Ubiquiti Cloud Gateway Industrial (UCG-Industrial 270W)

The Ubiquiti Cloud Gateway Industrial (UCG-Industrial 270W) is a ruggedized, fanless 10GbE UniFi Cloud Gateway engineered for high-density PoE deployments and advanced network management. Delivering up to 350W total system power and supporting the full UniFi Application Suite, it provides enterprise-grade routing, security, and integrated WiFi performance in a compact industrial-ready design.

Designed for demanding environments, it features integrated WiFi 6/7 support, multi-WAN capability, 5 Gbps IDS/IPS throughput, and pre-installed microSD storage for NVR functionality.

Key Features

• Ruggedized & Fanless Design – Built for industrial and high-demand deployments
• 350W Total System Power – Supports high-density PoE devices
• Advanced Security – Stateful firewall, Layer 7 firewall, IDS/IPS (55,000+ signatures)
• Multi-WAN Support – Load balancing and failover
• Integrated WiFi 6 & WiFi 7 – High-speed wireless connectivity
• Full UniFi Application Support – Network, Protect, Access, Talk & Connect
• Pre-installed 128GB microSD – Built-in NVR capability
• 5 Gbps IDS/IPS Throughput
• PoE+++/PoE+ Ports – Up to 90W per PoE+++ port

UniFi Management Capacity

• 50+ Managed UniFi Devices
• Up to 500+ Simultaneous Users
• Supports 15 HD, 8× 2K, or 5× 4K Cameras
• Max WAN Ports: 5

Integrated WiFi Performance

• WiFi Standards: WiFi 6 & WiFi 7 (802.11ax/be)
• 5 GHz Throughput: Up to 4.3 Gbps
• 2.4 GHz Throughput: Up to 688 Mbps
• MIMO: 2x2 MU-MIMO (DL/UL)
• Coverage Area: 115 m² (1,250 ft²)

Security & VPN Features

• Application-aware firewall & DPI
• Zone-based filtering (Regions, Domains, Apps)
• Content filtering & Ad blocking
• Site-to-Site VPN (IPsec, OpenVPN, Site Magic)
• WireGuard, L2TP & Teleport VPN
• License-free SD-WAN
• Advanced NAT & VLAN segmentation

Technical Specifications

The UCG-Industrial 270W is purpose-built for industrial and enterprise environments that demand reliable routing, advanced security, integrated WiFi, and high PoE capacity — all managed seamlessly within the UniFi ecosystem.
